DP Series Information



  • .100 [2.54] x .100 [2.54] Grid spacing.
  • 3 Row Design
  • 48, 96, 120 and 150 Contact Positions
  • Compliant or Solder tails
  • Selective contact plating in mating and tail sections.
  • Variable length contact staging.
  • 3 amp Rating per contact @ 20 degrees Celsius.
  • Removable insulator for easy reparability.
  • Double compliant contact design offers easy replacement of damaged contacts from front or rear of backpanel.
  • Selective contact loading and Staging.
  • Insulators only available for use as shrouds.
  • Compatible with other DIN "41612" connector systems.
  • Agency Approval



  1. Contact Staging for First Mate/Last Break contact sequencing
  2. Polarization Keying
  3. Compliant (shown) or Solder Tails
  4. Removable Insulator
  5. Compliant section in insulator allows for contact staging.
