DS Series Information



  • .100 [2.54] x .100 [2.54] Grid spacing.
  • 2 and 3 Row Design
  • 48 and 96 Contact Positions
  • Compliant or Solder tails
  • Twin beam contact design for high reliability.
  • 3 amp Rating per contact @ 20 degrees Celsius.
  • Closed Insulator Entry system prevents damage of contacts.
  • Selective contact loading.
  • Compatible with other DIN "41612" connector systems.
  • Agency Approval



  1. Closed Contact Entry
  2. Polarization Keying
  3. Integral contact preload for reduced insertion force
  4. Compliant (shown) or Solder Tails
